| MODEL |
UNIT |
KPM - 30 |
KPM - 60 |
|
 Injection Unit |
|
| SCREW DIAMETER |
MM |
28 30 |
30 35 |
|
| L/D RATIO |
|
14:1 15:1 |
15:1 15 |
|
| MAX. SHOT VOLUME |
C.C. |
68 72 |
95 130 |
|
| SHOT CAPACITY (P.S.) |
GM |
60 70 |
90 110 |
|
| MAX. INJECTION PRESSURE |
KG/CM2 |
1000 1200 |
1500 1200 |
|
| SCREW SPEED |
R.P.M. |
250 |
250 |
|
| INJECTION STROKE |
MM |
100+10 |
110+10 |
|
| HOPPER CAPACITY |
LTR. |
10 |
15 |
|
| NOZZLE RETRACTION STROKE |
MM |
115 |
175 |
|
| NOZZLE CONTACT FORCE |
KN |
37 |
46 |
|
| CLAMPING UNIT |
|
|
| MOULD PLATEN SIZE (H X V) |
MM |
350 X 240 |
450 X 400 |
|
| CLEARANCE BETWEEN TIE BAR |
MM |
250 X 250 |
300 X 250 |
|
| MAX. MOULD OPENING |
MM |
200 |
225 |
|
| MIN./MAX. MOULD THICKNESS (FIX SIDE) |
MM |
50 - 100 |
75 - 150 |
|
| MIN./MAX. MOULD THICKNESS |
MM |
100 - 220 |
125 - 300 |
|
|
| HYD. EJECTOR STROKE |
MM |
50 |
75 |
|
| HYD. EJECTOR FORCE |
KN |
1 |
2 |
|
| GENERAL DATA |
|
|
|
| OIL TANK CAPACITY |
LTR. |
100 |
150 |
|
Mould height Adjustment with gear Mechanism to Reduce mould Setting time.
